Product Details:
Payment & Shipping Terms:
|
| Usage: | Welding | Laser Power: | 1000/1500/2000W |
|---|---|---|---|
| Laser Wavelength: | 1080+-5nm | Warranty Of Core Components: | 3 Years |
| Output Fiber Length: | 15m | Materials:: | Metal, Steel Iron Aluminum Carbon Steel |
| Power Required: | AC220V / 380V | Place Of Origin:: | Anhui, China |
| Highlight: | Brass Handheld Fiber Laser Welding Machine,Copper Handheld Fiber Laser Welding Machine |
||
Handheld Fiber Laser Welding Machine For Stainless Steel Iron Aluminum Copper Brass
Our Laser welding machine laser welding technology is very mature. Many advantages such as simple operation, beautiful welding line, fast welding speed, and no consumables.
The machine is equipped with 15-meter optical fiber, which can realize long-distance, flexible welding in large areas and reduce operating limitations.
Hand-held laser welding machines can be widely used in stair elevators, kitchen cabinets, shelves, ovens, stainless steel doors, window guardrails, distribution boxes, stainless steel homes, and other industries.
| Model | GK1000/GK1500/GK2000 |
| Power | 1000W/1500W/2000W |
| Laser wavelength | 1080nm |
| Operating temperature | 10 - 50°C |
| Working humidity | <95% |
| Min seam width | 0.1mm |
| Power Modulation Rate | 50KHZ |
| Power Voltage | 220VAC/50Hz/60Hz |
| Beam Quality square meter | 1.3 |
| Fiber optical length | 15M |
| Weight (KG) | 150KG |
| Certificates | CE&GSG&ISO |
| Typical thickness of Stainless steel | 1-3mm |
| Typical thickness of Mild steel | 1-3mm |
| Typical thickness of Aluminum | 1-3mm |
